Module
SIMCOM 8300G, Telit, Qualcomm, Fibocom M.2 card
5G
Sub 6G n1,2,3,5,7,8,12,20,25,28,38,40,41,48,66,71,77,78,79
LTE
Band 1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/29/30/38/41/42
UMTS
Band 1/2/4/5/8
Speed
•5G Sub 6GHz• SA max2.4Gbps(downlink)、1Gbps(uplink)•NSA max3.4Gbps(downlink)、600Mbps(uplink)•LTE max1.6Gbps(downlink)、200Mbps(uplink)•HSPA+ max42Mbps(downlink) 5.76Mbps(uplink)
GNSS(optional)
QZSS、GPS、GLONASS、Galileo、BeiDou
WiFi 7(optional)
•Wi-Fi 7: 2.4(40MHz)+5(160MHz)+6(320MHz)=19Gbps
•6GHz (320MHz, 4K-QAM) 11–13Gbps PHY
•5GHz (160MHz, 4K-QAM) 5–6Gbps PHY
•2.4GHz 1Gbps PHY

Interface
• 1xSFP+ 10G WAN(optional), 1xRJ45 2.5GBE WAN, Ethernet *4x1GBE LAN (2 for
   802.3at PSE(PoE+) LAN 30W for IP cam.
• SIM card Interface(3V/1.8V)、e-SIM(optional)• WiFi 4T4R for external tri-band• 5G、LTE for external antennas interface4pcs
• MicroSD card.
• DI*2,DO*2, RS-485*2, half-duplex isolation，with 2KV
• Reset button*1 (Factory reset)
• LED (Power, System, Ethernet, Internet)
• Support last gasp after power is down.

Button
System reset
LED
WiFi 2.4G,WiFi 5/6G WAN/LAN, Internet、 System.
Embedded Systems
• Linux: OpenWRT
Protocol
TCP、FTP、PPTP、HTTP、HTTPS、TFTP、DHCP、NAT、IPSec Passthrough、QoSoptional: VPN Clients and gateways, IPSec clients
Cellular interface
• Selectable between 1x4G miniPCIe card or 1xM.2 5G card(Default 4G)
• (Optional) 2xPCI card for MTK WiFi7 module AW7256-P01 (BE19000-class)
10G SFP+(optional)
•1x10G SFP+ cage for WAN
•1x10G SFP+ cage for LAN
PSE LAN
•2xPSE 802.at(PoE+) 30W output for IP cam
10G GBE (optional)
• 1x10G GBE WAN, 1X10G GBE LAN
Specifications
• Size15.5x12 x 2.5cm.
• Weight 0.5Kg
• Certificate: NCC、BSMI(TBD)
